eGo S200W
AHONY
BP107020013400151
760*1165*3mm
Boat RV Camper Car Roof Balcony Motorhome Golf Cart Camping High Efficient Lightweight Thin Film Walkable Bendable PV Module Kit System
25.8% to 27.4%
1.Technical parameters
| Model No. | eGo S200W |
| Product Name | Semi flexible solar panel |
| Maximum Power[Wp] | 200 |
| Solar Cell | Back Contact Solar Cell |
| Cell Efficiency | 25.80% |
| Size[mm] | 760*1165*3 |
| Max Power Voltage Vmp[V] | 28.12 |
| Max Power Current Imp[A] | 7.11 |
| Open Circuit Voltage Voc[V] | 32.90 |
| Short Circuit Current Isc[A] | 7.54 |
| Net.Weight[kg] | 2.90 |
| Power tolerance[%] | 0 to +3% |
| Operating Temperature[℃] | -40/+85 |
| Temperature Coefficient Pmax[%/K] | -0.3 |
| Temperature Coefficient Voc[[%/K] | -0.26 |
| Temperature Coefficient Isc[[%/K] | 0.05 |
| Maximum System Voltage[V] | 1000 V |
| Maximum Fuse Rating[V] | 25A |
| Flame retardancy | UL94 VTM-0 |
| Certification and test | CE,ROHS,SGS,IEC salt mist,High temp humidity test |
| Maximum bend radius(θ) | 60° |
| Jbox | waterproof Jbox IP67 XC502 |
| Cables and Connectors | 0.9m 4m㎡+MC4 |
| Holes and eyelets[pcs] | 6,stainless steel 316 |
2.About 200W flexible solar panel
AHONY – Direct Manufacturer of 200W Flexible Solar Panels & Full Range HPBC PV Modules for 12V/24V/48V Off-Grid Systems
AHONY 200w semi flexible solar panel uses leading efficiency ABC or HPBC solar cells,it has little cell gap space,and minimum size,max power at same space.
Shingle design with almost no cell gap,while the lifespan is much longer then shingle solar modules.
Are you a wholesaler, installer, or solution provider looking for high-efficiency, lightweight, and durable flexible solar panels? Look no further than AHONY. As a leading manufacturer, we specialize in a full spectrum of flexible HPBC PV modules ranging from 50W to 500W, perfectly compatible with 12V, 24V, and 48V off-grid systems.
2.Features and Key Advantages
1)HPBC Cell Technology:
Utilizing next-generation HPBC (Hybrid Passivated Back Contact) cells, our panels offer higher conversion efficiency and better performance in low-light conditions compared to traditional poly/mono panels.
2)Extreme Flexibility & Lightweight:
Designed for curved surfaces. Our 200W panel weighs 70% less than standard glass panels, making them ideal for RV roofs, boat decks, and balcony railings where weight and wind load are concerns.
3)Universal Voltage Compatibility:
Fully optimized for 12V, 24V, and 48V battery banks. From our small 50W maintenance chargers to our industrial 1000W systems, we have the exact wattage you need.
4)Durability for Harsh Environments:
IP68 rated, UV resistant, and anti-corrosion. Specifically engineered for marine and outdoor mobile living—no glass, no broken cells, no frame rust.
5)Easy Installation (No Drilling Required):
Perfect for non-load-bearing roofs. Install with strong adhesives, grommets, or cable ties without penetrating the substrate.
6)Customization Service:
OEM/ODM welcome. We can customize labels, cables, connectors, and even layup patterns for your specific project requirements.
3.Benifits of choosing this flexible solar panel
High turnover product with lower shipping cubic volume (flat packaging) and fewer breakage claims.
No roof racking required on rv,caravan,trailer conversion; low profile reduces wind noise and improves fuel economy;Bend to fit the aerodynamic curve of the modern camper.
Saltwater corrosion resistant on boat,marine industry,yacht,catamaran,Non-slip surfaces;bifacial gain from deck reflection.
Scalable solution for fence balcony or tensile structure integration.
Lightweight retrofitting for industrial warehouses,experience design,R&D etc engineering work for engineering companies.
Powering traffic sensors and 5G nodes on curved poles,offer innovated and advanced products for Smart City & IoT.
Valuable design,customize solar panels,size,voltage to help you better optimize your portable power station ecosystem,or battery storage solutions,like camera system,marine solar system,MPPT charging system,remote power station,mobile paying etc.
All-black, ultra-thin, and bendable — mounts flush on curved or weight-sensitive surfaces without structural modification.
Our 200w semi flexible solar panel and this series are mainly serve for:
Wholesalers & Retailers: AHONY offers competitive factory pricing and bulk stock availability.
RV & Caravan Converters: Ultra-light, bendable panels that conform to curved roofs.
Marine & Yacht Owners: Corrosion-resistant, salt-water proof materials.
Balcony & Terrace Users: Plug-and-play solutions for urban solar generation.
Non-Load-Bearing Roof Installers: Zero roof penetration options with high weight-to-power ratio.
Solar Solution Companies: Customizable sizes and voltages for specialized applications.
More than 10years experience solar factory,our product got ISO9001,ISO14001,CE ROHS,IEC61215 IEC61730,UKCA,VOC etc certification,sell overseas.
Factory Direct Pricing – No middlemen, better margins for you;
Consistent Quality – Strictly tested HPBC cells & ETFE material;
Fast Lead Time – Ready stock for samples; efficient production for bulk orders;
Technical Support – Installation guides, datasheets, and after-sales service;
Global Shipping – Secure packaging for air and sea freight.
We are currently expanding our B2B partnerships with distributors, RV manufacturers, solar solution integrators, and engineering firms. OEM/ODM customization is also available.
