eGo S120W
AHONY
BP107020011000116
580*935*3mm
Boat RV Camper Car Roof Balcony Motorhome Golf Cart Camping High Efficient Lightweight Thin Film Walkable Bendable PV Module Kit System
25.8% to 27.4%
1.Technical parameters
| Model No. | eGo S120W |
| Product Name | Semi flexible solar panel |
| Maximum Power[Wp] | 120 |
| Solar Cell | Back Contact Cell |
| Cell Efficiency | 25.80% |
| Size[mm] | 580*935*3 |
| Max Power Voltage Vmp[V] | 18.75 |
| Max Power Current Imp[A] | 6.40 |
| Open Circuit Voltage Voc[V] | 21.94 |
| Short Circuit Current Isc[A] | 6.78 |
| Net.Weight[kg] | 1.60 |
| Power tolerance[%] | 0 to +3% |
| Operating Temperature[℃] | -40/+85 |
| Temperature Coefficient Pmax[%/K] | -0.3 |
| Temperature Coefficient Voc[[%/K] | -0.26 |
| Temperature Coefficient Isc[[%/K] | 0.05 |
| Maximum System Voltage[V] | 1000 V |
| Maximum Fuse Rating[V] | 25A |
| Flame retardancy | UL94 VTM-0 |
| Certification and test | CE,ROHS,SGS,IEC salt mist,High temp humidity test |
| Maximum bend radius(θ) | 60° |
| Jbox | waterproof Jbox IP67 XC502 |
| Cables and Connectors | 0.9m 4m㎡+MC4 |
| Holes and eyelets[pcs] | 6,stainless steel 316 |
2.Product Introduction
AHONY is proud to introduce our latest 120W Flexible Solar Panel, engineered with advanced HPBC (Hybrid Passivated Back Contact) cell technology. Designed for the modern mobile lifestyle and off-grid independence, this panel is the ideal power solution for RVs, boats, cabins, trailers, curved roofs, and 12V battery charging systems.
As a direct manufacturer, AHONY offers OEM/ODM customization, competitive wholesale pricing, and reliable supply chains. We invite global distributors, retailers, system integrators, and project engineers to partner with us for durable, high-yield solar solutions that outperform traditional rigid panels in form and function.
2.Features and Key Advantages
Utilizes next-generation Hybrid Passivated Back Contact (HPBC) cells.
Higher energy conversion efficiency than standard monocrystalline panels.
Excellent performance in shaded or low-light conditions (cloudy days, dawn/dusk).
Extreme bendability (up to 60° arc) – conforms perfectly to curved RV roofs, boat decks, and camper tops.
Ultra-thin and lightweight (70% lighter than glass panels) – no mounting rails or heavy brackets required.
Made with ETFE lamination – superior to standard PET, with higher light transmittance and anti-yellowing properties.
IP68 waterproof rating, corrosion-resistant, and anti-scratch surface.
Withstands harsh marine and highway conditions – salt spray, vibration, and high wind tested.
Optimized for 12V battery systems – ideal for RVs, boats, off-grid cabins, and solar generators.
Compatible with PWM/MPPT controllers, charge regulators, and inverters.
Includes pre-wired junction box with MC4 connectors for fast installation.
Mounting options: adhesive, grommets, or cable ties.
No drilling required – preserves roof integrity and prevents leaks.
Perfect for rental fleets, mobile applications, and retrofitting.
Customizable size, wattage, connector type, and packaging.
Private labeling and logo printing supported.
Bulk orders with fast turnaround and consistent quality control.
3.Benifits of choosing this flexible solar panel
High-turnover SKU for off-grid & mobile living market for Wholesalers & Retailers;
Pre-installation on curved roofs during production for RV/Boat Manufacturers;
Add-on for portable power stations & campervan builds for Solar Solution Integrators;
Lightweight alternative for load-limited roofs for Engineering Companies;
Ready-to-ship flexible,packing,visual identification designing with strong visual appeal for E-commerce Sellers
Factory Direct Pricing – No middlemen, better margins for you;
Consistent Quality – Strictly tested HPBC cells & ETFE material;
Fast Lead Time – Ready stock for samples; efficient production for bulk orders;
Technical Support – Installation guides, datasheets, and after-sales service;
Global Shipping – Secure packaging for air and sea freight.
